AutoRebar (v3.4.2) for AutoCAD
Those of you who often draw concrete rebar details in AutoCAD surely know, drawing rebar one by one manually takes a lot of time. Luckily there is AutoRebar Full (v3.4.2) that can add a special toolbar in AutoCAD. The toolbar contains tools to create bars much faster, just click and set parameters. Supports AutoCAD 2013 to 2027, including the latest version. The 8.63 MB file is available below. 🔥
I once worked on a project, almost 40 concrete beam and column details, and most of the time was spent just drawing rebar. When using AutoRebar, time efficiency improved a lot. Just set a little, directly done.
The toolbar is complete, with special objects like Rebars, Marks, Callouts, to Bar Bending Schedule. Changes in one object also directly update other elements in real-time! Besides that, BBS can also be exported to Excel.
For a more complete civil engineering workflow, AutoRebar can be combined with Autodesk Civil 3D 2026 for road and foundation design. If you need the main CAD software, Autodesk Revit 2026.
Go, download AutoRebar v3.4.2 to try it yourself. 👍
AutoRebar Latest Features and Download Link :
- Special toolbar in AutoCAD makes rebar detailing much faster.
- Uses special objects like Rebars, Marks, Callouts, and BBS.
- Changes in one object directly update other elements in real-time.
- Export Bar Bending Schedule to Excel.
- Supports AutoCAD 2013 to 2027, including the latest version.
- Automatic rebar marks numbering and BBS generation from drawings.
- Optimized for Windows 10/11 Pro 64-bit.
- Supports various types of reinforced concrete structural details.
User Interface :
System Requirements :
| Operating System | Windows 10 | 64 Bit Only |
|---|---|---|
| Processor | Intel 3Ghz Dual-Core | Intel Core i7 Processor 3Ghz+ |
| Memory | 8 GB DDR3 | 32 GB DDR4 |
| Hard Drive | 5 GB – 7200 RPM HDD | 5 GB – Solid State Disk |
| Graphics Card | Dedicated GPU Card | NVIDIA GTX 1660 or Above |
| Screen Resolution | 1920×1080 | 3840 x 2160 |
Steps to Install AutoRebar on Your PC :
- Download the ARBR342i.rar file (8.63 MB) from the link below.
- Extract the file using WinRAR or 7-Zip.
- Open folder 1, run AutoRebar_2027_Full_v3.4.2.msi and install.
- Then open the Readme.txt file for further guide.
- Good luck! 😁
